FS-19P-100 Filter Assembly

Whirlwind Regenerative blowers are top quality. The motor is designed with a high service factor for years of reliable performance. The Whirlwind R4247 Regenerative Blower has 1" ports, pre-wired with 120VAC cord, dual voltage 120vac/220vac, fits Hoot/TroyAir H500, H600, Bio-Microbics/MicroFAST 05, 0.625 and other 500-650 gallon per day systems.

Hoot Troy Air is a Registered Trademark of Hoot Aerobic Systems, Inc.

MicroFAST a Registered Trademark of Bio-Microbics, Inc.

Warranty

The Whirlwind R4247 Regenerative Blower comes with an 18-month limited warranty.

The FS-19P Filter Element is for Gast Regenerative Blowers. Includes a polyurethane prefilter which increases the dust loading capacity from 40% to 50%. Filter element has a 3" inside diameter and a 4-3/8" outside diameter.

Fits FS-19P1-100, FS-19P-125, FS-19P-150 filter assemblies. For use with R-5760, R2103, R3105-12, R4110-2, R5125-2 Gast Regenerative Blower models.

The Gast R2103 Regenerative Blower is used for high volume vacuum or compressed air applications. Used in a wide range of applications including sewage aeration and aquaculture. The R2103 TEFC electric motors are UL and CSA approved with permanently sealed ball bearings.

Gast R2103 Regenerative Blowers have a maximum air flow 42 CFM (60 Hz), 33 CFM (50 Hz), maximum pressure of 39" H2O (60 Hz), 30" H2O (50 Hz), and maximum vacuum of 35" H2O (60 Hz), 25" H2O (50 Hz). The R2103 has a power rating of 1/3 - 1/2 hp.

Warranty

We offer a 1-year limited warranty on all Gast Regenerative Blowers.

The Red Alert P101-2 Control Panel is a superior replacement for panels used with septic tank aerators. This control panel is compatible for use with air pumps, vane pumps, regenerative blowers, and linear style aerators manufactured by brands such as Whirlwind®, Hiblow®, Gast®, Secoh®, as well as alternative high-quality replacement units like the ones produced by Septic Tank Parts. This unit is not to be used with shaft-style aeration systems.

For shaft-style aerators, use the Red Alert P101FA-2 Control Panel.

The Red Alert control panel is manufactured for longevity in indoor and outdoor use. Crafted from industrial-grade plastics, UL-rated weather-resistant housing, and anti-corrosive zinc-plated screw terminals, this control panel is resistant to wear and temperature extremes.

With the Red Alert™ 24-time control technology, the P101-2 is completely programmable with a control timer, warning light, and a 3-position toggle switch that allows the unit to be on/auto; off; or in continuous run mode. The ability to program down to 15-minute intervals gives you precise control over your aerator scheduling.

Warranty

We offer a 2-year limited warranty on Red Alert Control Panels.

The FS-19P-125 Filter Assembly is for use with Whirlwind R5760 and R3105-12 Regenerative Blowers. Includes a FS-19P Filter Element.
