Male Waterproof Plug End

The Flagg-Air® 340HT-N Septic Aerator is a brand-new, not refurbished, shaft-style septic aerator with 14” brackets designed specifically for use in Norweco Singulair®* tanks as a premium OEM replacement for ALL Norweco Singulair® aerator units (including models 96, 960, 206C and 780), Alpha Air model AL500-14, and model 735.

The Flagg-Air® 340HT-N Septic Aerator features a low RPM with high CFM, fully enclosed continuous duty motor with 2-foot power cord; pre-lubricated and sealed bearings; and a 7-amp mini breaker. This shaft-style aerator has a 304 stainless-steel aerator shaft, bronze coupler, and powder-coated steel brackets that have rubber vibration restrictors to provide improved mounting stability and bearing life. The Flagg-Air® 340HT-N Septic Aerator uses only high-impact plastic for the suds restrictor, aspirator, and the 3-in-1 T-Bar handle.

The distinguishing difference between the 340HT Series Flagg-Air® aerators is bracket size. The FA340HT-N is a Norweco Singulair® septic aerator alternative with 14-inch brackets designed to fit the 12” diameter tank opening of Norweco Singulair® aerobic septic systems. The FA340HT-J is a Jet®** septic aerator replacement with 12-inch brackets designed to fit the 10” diameter tank opening in Jet® aerobic septic systems. Norweco Singulair® aerators will be blue and Jet® septic aerators will be red. Measure your tank opening to determine which aerobic septic system pump replacement to buy or call our Customer Service at (800) 778-1540 for assistance.

Every Flagg-Air® Septic Aerator includes a separate 7-amp mini circuit breaker to protect the motor. Installation of this mini breaker is required for warranty purposes. If you are replacing a Flagg-Air® septic shaft aerator, it is recommended to replace an existing 7-amp breaker with the new one that was shipped with your unit.

The Flagg-Air® 340HT-J Septic Aerator is a brand-new, not refurbished, shaft-style septic aerator with 12” brackets designed specifically for use in Jet®* tanks as a premium OEM replacement for ALL Jet® aerator units (including models 660, 665, and 700LL), Alpha Air AL500-12 model, and model 735.

The Flagg-Air® 340HT-J Septic Aerator features a low RPM with high CFM, fully enclosed continuous duty motor with 2-foot power cord; pre-lubricated and sealed bearings; and a 7-amp mini breaker. This shaft-style aerator has a 304 stainless-steel aerator shaft, bronze coupler, and powder-coated steel brackets that have rubber vibration restrictors to provide improved mounting stability and bearing life. The Flagg-Air® 340HT-J Septic Aerator uses only high-impact plastic for the suds restrictor, aspirator, and the 3-in-1 T-Bar handle.

The distinguishing difference between the 340HT Series Flagg-Air® aerators is bracket size. The FA340HT-J is a Jet® septic aerator replacement with 12-inch brackets designed to fit the 10” diameter tank opening in Jet® aerobic septic systems. The FA340HT-N is a Norweco Singulair® ** septic aerator alternative with 14-inch brackets designed to fit the 12” diameter tank opening of Norweco Singulair® aerobic septic systems. Jet® septic aerators will be red and Norweco Singulair® aerators will be blue. Measure your tank opening to determine which aerobic septic system pump replacement to buy or call our Customer Service at (800) 778-1540 for assistance.

Every Flagg-Air® septic aerator includes a separate 7-amp mini circuit breaker to protect the motor. Installation of this mini breaker is required for warranty purposes. If you are replacing a Flagg-Air® septic shaft aerator, it is recommended to replace an existing 7-amp breaker with the new one that was shipped with your unit.

Designed to remotely operate your shaft-style aerator, the Red Alert P101FA-2 Control Panel is a compatible replacement for Jet®* and Norweco Singulair®** control panels as well as corresponding alternative aerators like the Flagg-Air 340HT-J and Flagg-Air 340HT-N models. This unit is designed specifically for shaft-style aerators.

For other types of aerator systems, see the Red Alert P101-2 Control Panel.

The Red Alert control panel is manufactured for longevity in indoor and outdoor use. Crafted from industrial-grade plastics, UL-rated weather-resistant housing, and anti-corrosive zinc-plated screw terminals, this control panel is resistant to wear and temperature extremes.

With the Red Alert™ 24-time control technology, the P101FA-2 is completely programmable with a control timer, warning light, 7-amp breaker, and a 3-position toggle switch that allows the unit to be on/auto; off; or in continuous run mode. The ability to program down to 15-minute intervals gives you precise control over your aerator scheduling.

The Red Alert P101FA-2 Control Panel also features a 7-amp mini breaker to protect your aerator. Fibrous debris, like hair, can get wrapped around the shaft of your aerator or water levels in the tank can get too high, making the motor work harder against this resistance. In these scenarios, the 7-amp mini breaker will trip, interrupting the current, causing the aerator to shut off rather than damage the motor. This gives you the opportunity to remove the debris before resetting the breaker and restarting the unit. The Red Alert P101FA-2 Control Panel’s breaker reset button is located on the front of the panel for easy access.

*Jet® is a registered trademark of Jet Inc. All original manufacturer's names, drawings and part numbers are used for identification purposes only and we are in no way implying that any of our products are original equipment parts, or are affiliated with, or endorsed or approved by the original manufacturers.

**Norweco Singulair® is a registered trademark of the Norwalk Wastewater Equipment Company, Inc. All original manufacturer's names, drawings and part numbers are used for identification purposes only and we are in no way implying that any of our products are original equipment parts, or are affiliated with, or endorsed or approved by the original manufacturers.

Warranty

We offer a 2-year limited warranty on Red Alert Control Panels.

Rubber Tips are used on Flagg-Air 340 and all other manufacturer's brackets requiring vibration dampers, sold in sets of 4.

If in need of rubber tips for upper and lower brackets, order two (2) sets for a total of 8 tips.
